TRFlex500Pro Specs
| Pixel pitch | P2.604mm | P2.976mm | P3.91mm(Flat) | P4.81mm(Flat) |
| LED Type | SMD1515 | SMD1515 | SMD2121 | SMD2121 |
| Density(dot/sqm) | 160000 | 112896 | 65536 | 43264 |
| Module Resolution | 96X96 | 84X84 | 64X64 | 52X52 |
| Module Size (mm) | 250X250 | 250X250 | 250X250 | 250X250 |
| Panel Resolution | 192X192 | 168X168 | 128X128 | 104X104 |
| Maintenance | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| Cabinet Frame | Aluminum | Aluminum | Aluminum | Aluminum |
| Brightness(cd/m2) | 800-5000 | 800-5000 | 800-5000 | 800-5000 |
| Color Temperature(K) | 3200-9300 | 3200-9300 | 3200-9300 | 3200-9300 |
| Grey Level(bit) | 14/16 | 14/16 | 14/16 | 14/16 |
| View Angle(H/ V) | 160° /160° | 160°/160° | 160°/160° | 160°/160° |
| Contrast Ratio | 5000/1 | 5000/1 | 5000/1 | 5000/1 |
| Frenquency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Drive Mode | 1/32 Scan | 1/28 Scan | 1/16 Scan | 1/13 Scan |
| Max Power Consumption | 800(w/m²） | 800(w/m²） | 800(w/m²） | 800(w/m²） |
| Avg Power Consumption | 200(w/m²） | 200(w/m²） | 200(w/m²） | 200(w/m²） |
| Power Requirment | AC220V,50Hz | AC220V,50Hz | AC220V,50Hz | AC220V,50Hz |
| The specifications are for reference, actual values may vary. | ||||
